REGRINDING AND COATING SERVICES
Regrinding and coating to the original manufacturer's specifications are available on all WIDIN tools. Please contact customer service for further assistance at customerservice@widinus.com
-
EDP#: VXR504A032030
1/2"x1/2"x5/8"x2-1/2"
.030 Corner Radius
Pocketing Operation
Shrink Fit Holder
2300 revolution per minute
25 inches per minute
0.4 depth of cut
.375 width of cut
Material: 4140 36 Hrc.
Cat 40 with 3.75 Inch Overhang Length -
EDP#: VXR524A032030F
1/2" x 1/2” x 1-1/4” x 3-1/4” & Weldon Flat
0.030 Corner Radius & Weldon Fat
Side Milling
3750 revolution per minute
70 inch per minute
.95 depth of cut
.05 width of cut
Material: P20, 40Hrc -
EDP#: SF508127
1/2" x 2.95" EFL x 5.24" TFL x 7.16" OAL x 13mm Shank
2 Flute, Single Margin, & Coolant Through
3300 Revolution Per Minute
25 Inches Per Minute
3.5 inch deep with thru hole Depth of Cut
Material: 4140 Steel 38 HRC
Cat 50 Collet Holder
