HPI508N
HPI508158N
![HPI508158N](http://widinus.com/cdn/shop/products/HPI508N_20DRILL_20POWER_20MAX_20METRIC_7fa7867e-11e5-4bfa-935a-a96b754b5df7_{width}x.jpg?v=1681304975)
- US: 5 units
- In-transit: 0 units
- Korea: 1 units
SERIES DESCRIPTION
• 2 FLUTE - 8XD CUT LENGTH - INTERNAL COOLANT - TiALN+HH COATING - METRIC • Double Margin • 140° point angle • Cutting diameter range = 3mm - 20mm • Good up to 50HRc • Excellent in alloy & stainless steel, cast iron and harden steels up to 50HRc"
Tolerance
~D3 = +0.012~+0.002mm D3 = +0.012~+0.002mm D3.1~D6 = +0.016~+0.004mm D6.1~D10 = +0.021~+0.006mm D10.1~D16 = +0.025~+0.007mm D18.1~ = +0.029~+0.008mm SHANK DIA. = h6
