NCNTHN TYPE

LC-4NCNTH-06

LC-4NCNTH-06

LIVE CENTER

Price
  • List:$597.88

  • US: 0 units
  • In-transit: 0 units
  • Korea: 0 units

SERIES DESCRIPTION

• NC STANDARD LATHE – SCREW THREAD & DRAW-OFF NUT TYPE - LIVE CENTER
• Screw thread & draw off nut type, appropriate model for NC lathes.
• Morse Tapers Available - No. 3 - No. 5
• Sealed to prevent the inflow of cutting oils, coolants and foreign substances
• High precision of rotational accuracy and durability through triplexed bearing structure
• Shaft heated to 58 - 62 HRc
• Run Out 0.00012" or 0.003mm

  • EDP NO
  • PART NO
  • MORSE TAPER
  • GL
  • A
  • B
  • b
  • d
  • d
  • L1
  • L2
  • L3
  • L4
  • L5
  • L6
  • C
  • D
  • E
  • G
  • H
  • N
  • P,C,D
  • T
  • L
  • MAX. WEIGHT (lbs)
  • RPM MAX
  • RUN OUT (inch)
    • LC-4NCNTH-06
    • 14011
    • NO. 4
    • 66
    • 14
    • 32.5
    • 53
    • 55
    • 6.5
    • 114.5
    • 101.5
    • 85
    • 66
    • 216
    • 1719.61
    • 3800
