XE515

XE515060

XE515060

END MILL

Price
  • List:$75.04

  • US: 5 units
  • In-transit: 0 units
  • Korea: 90 units

SERIES DESCRIPTION

• SQUARE - 5 FLUTE - REGULAR CUT LENGTH, TiALN+SH Coating - METRIC • Variable helix tools • High precision with excellent surface finish due to each 4F variable helix geometry • Unique patented design decreases chatter and resonance • Strong cutting edge allowing for increased depth of cut at elevated feed & speeds • Higher feed & speeds for increased productivity • Reduced vibration harmonics • Excellent performance on carbon, alloy & prehardened steels, copper & stainless steels

Tolerance

D1~D8 = 0~-0.04mm D10~D25 = 0~-0.05mm SHANK DIA. = h6

  • EDP NO
  • PART NO
  • FLUTES
  • CUTTING LENGTH
  • CUTTING DIAMETER
  • OVERALL LENGTH
  • SHANK DIAMETER
  • NECK LENGTH
  • CORNER RADIUS
  • END CUT TYPE
  • LETTER SIZE
  • TAPER DEGREE
  • POINT ANGLE
  • COATING
    • XE515060
    • 472001
    • 5
    • 25
    • 6
    • 75
    • 6
    • SQUARE
    • 6
    • TiAlN-SH
